Tauira No.: LTN154X9-L01
Ltn154x9-L01 Kua whakauruhia tenei waahanga ki te rama CCFL, kaore he taraiwa o muri, kaore he pa. Ko ona ahuatanga angamaheni ko: te mata whakaata. Ko tana pāmahana whakahaere ko te 0 ~ 50 ° C, me tana pāmahana rokiroki ko -20 ~ 60 ° C.
Ko te whakataunga whakaatu a Ltn154x9-L01 ko te 1280 (RGB) × 800 (WXGA), ko te ōwehenga ōwehenga ko 16:10 (te whanui: te teitei), ka whakaritea nga pika ki nga whiu rgb. Ko te rahi o te raarangi whakaatu ko te 331.2 × 207 (whanui × × 210 × 210.7 (whanui) × 7 (matotoru) mm. Ka whakamahia ki te mata whakaata (haze 0%), paninga pakeke (3h).
Q: He aha te ratonga o mua-hoko me muri-hoko?
A: Mo nga ratonga o mua-hoko, kei a maatau te roopu hoko ngaio me te roopu hangarau, e pai ana ki te whakautu i o patai i roto i te 24 haora.
Q: Me pehea e kitea ai e ahau te hua tika?
A: Tukuna mai ki a maatau hiahia, ka tūtohu matou i o maatau hua paerewa, mena kaore e pai, ka mahia e maatau te whakatikatika me te whakarite.
| brand | SAMSUNG | Model name | LTN154X9-L01 |
| size | 15.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 | Pixel configuration | RGB vertical bar |
| Display Area | 331.2×207(H×V)mm | Surface treatment | Glare (Haze 0%), Hard coating (3H) |
| Visual size | 335.0×210.7(H×V)mm | Contrast Ratio | 600:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 344×226×7(H×V×D)mm |
| Viewing Angle | 65/65/50/50 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | LVDS (1 ch, 6-bit) ,erminal,30pins |
|
|
| supply voltage | 12.0V (Typ.) |
|
|
Nga Taonga Hot: 15.4 inihi Samsung Ltn154x9-L01, Haina, Factory, Utu, Whakatakotoranga Matapihi, Maamaa te mata o te LCD. LCD , LCD Paewhiri LCD, LCD kōwae, whakaatu kanapa nui.
