Min. Whakatau:1 Piece/Pieces
Tauira No.: LQ150X1LG96
Ko te pāmahana mahi o te LQ150X1LG96 he 0 ~ 65 ° C, me te pāmahana rokiroki ko -30 ~ 70 ° C. He pai mo nga tono ahumahi, nga tohu o waho, nga kemu. Ko te maimoatanga mata he matte, he paninga pakeke (3h), me te taumaha kupenga o te hua ko te 950g (max.). I runga i nga ahuatanga o te maarama, ko te puna marama-momo he roa o nga haora 30k.
Ko te whakatau a LQ150X1LG996 te whakaaturanga whakaatu ko te 1024 (RGB) × 768 (XGA), ko te waahanga ōwehenga ko te 4: 3 (te whanui: teitei) Ko te rahi o te rahi o te LQ150X1LG96 ko 304.128 × 228.096 (W × H) MM, ko te rahinga o waho ko te 326.5 (H) × 10.1 (D) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Taonga wera: 15inch sharp lq150x196 TFT LVDS Paewhiri, Haina, Taakapa, Utu, Utu, Whakapauhia te Matapihi mo te TV, Maatauranga Matapihi mo te TV Te Paewhiri LCD 2500 Nits , LCD Paewhiri LCD, LCD kōwae, whakaatu kanapa nui.
LQ150X1LW96 SHARP TFT LCD Paewhiri LVDS mata
LQ156M1LG21 New Sharp TFT-LCD Mudle
