Min. Whakatau:1 Piece/Pieces
Tauira No.: TDA150-005V01
TDA150-005v01 A-SI TF-LCD 15-inihi te karaihe wai tioata, ko nga ahuatanga o te rama ma, tae atu ki te taraiwa a LED, te mata o te papa. Ko tana pāmahana whakahaere ko -20 ~ 70 ° C, me tana pāmahana rokiroki ko -30 ~ 80 ° C. Ko te whakatau whakaatu ko te 1600 (RGB) × 1200 (Uxga), ka whakaritea nga pika i nga whiu rgb. Ko te rahi o te waahanga whakaatu ko te 304.8 × 228.6 (W × H) mm, me te inenga o waho ko te 317.4 (W) × 242 (H) mm.
Ko te puna marama-a-kanohi me te roa o te haora 30k, tae atu ki nga taraiwa arataki. TDA150-005v01 Whakatutuhia nga LVDS (2 Ch, 8-Bit), e 40 pine, e hono ana i nga waahanga, ko te huringa taraiwa te 3.3v (Ty.
Q: Ko wai tatou?
A: R-whetu i ahu mai i Shenzhen, Haina, he kaiwhakanao ngaio o te mutunga o te mutunga o te mutunga, ka taea e matou te whakaatu mai i te 100 nga kaimahi, tae atu ki nga miihini mohio. Kua paahitia e te kamupene Iso9001 / ISO14001 / CCC / CCC / FCC / UL me etahi atu tohu, he hoa nui-om o te akomanga o te akomanga. Amerika, Africa, Middle East, Europe, Central and South and South and South and South Me Te Mea Ki Te Whakapaipai koe i a China.
Q: He kaiwhakanao koe (wheketere)?
A: Ae, ko matou. Kei te waatea ano hoki a OEM / ODM i konei.Elcon ki te whakapuaki i o whakaaro ki a maatau. Ko ta matou pai ki te whakarato otinga tino pai mo koe.
Q: Me pehea e taea ai e tatou te kii i te kounga?
A: I nga wa katoa e tirotirohia ana i mua i te tuku.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Ko te taua rahi me te tauira ko te whai ake:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
