Huanga Hua

Tauira No.: EV101WXM-N81

Packaging & Tukunga

Hoko Hoko:

Piece/Pieces

Kupu whakataki

EV101WXM-N81 He waahanga LCD LCD 10.1-inihi ma te whakamahi i te hangarau A-SI TF-LCD. Kua whakauruhia ki te rama rererangi, tae atu ki te taraiwa taraiwa arataki, kaore he pa. Ko te whakataunga whakaatu ko 1280 (RGB) × 800 (WXGA), 16:10 (whanui: Ko te rahi o te waahanga whakaatu ko te 216.96 × 135.6 (whanui × × 138.0 (whanui × 10.4 (matotoru o waho. (TYP.). Mo nga korero o te maarama, ka whakamahi tenei hua i tetahi punanga o te taha ki te taha o te rima me te ora 50k, tae atu ki te taraiwa arahi. EV101WXM-N81 Whakamahia te LVDS (1 Ch, 8-bit), e 20 nga titi, e whakamahi ana i te hononga urunga, te huringa mata o te mata 3.3V. Ko tana reanga whakahekeheketanga noa FV ko te 60Hz. Ka whakahaerehia i te -20 ° C ki te 70 ° C me nga toa i te -30 ° C ki te 80 ° C. I runga i tana rama rama ma, neke atu i te 50,000 haora te ora.

I ahu mai a R-Star i Shenzhen, Haina, he kaihanga ngaio o te mutunga o te mutunga o te tau, tae atu ki te LCD-waho, tae atu ki te mata o waho, te Ultrathin Hipanga LCD, Ahumahi Tohu-LCD, maamaa me te whakaaturanga whakaatu, te rua-taha-rua-roa-rua-rama-rua-rama me etahi atu paewhiri LCD teitei. I roto i te poto, he nui ake i te 5 nga tau o te hoahoa hangarau o te pouaka whakaata, te rangahau me te whanaketanga, te kaha whakaputa, 10 tau o te mekameka kounga nui.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Ko te tauira rahi me nga tohu e whai ake nei

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
