Min. Whakatau:1 Piece/Pieces
Tauira No.: BA104S01-100
Ba104S01-100 he hua noa 10.4-inihi LCD i whakarewahia e Boe Hangarau Group Count Co., Ltd. (Boe) Ma te whakamahi i te hangarau A-SI TF-LCD. Kei te rite ki te rama rererangi, kaore he puku o muri me te pa atu. Ba104S01-100 E whakaatu ana i te whakataunga o te 800 (RGB) .1 I tukuna e Boe i te Hakihea 12, 2014. Ko te rahi o te whakaaturanga whakaaturanga 211.2.4 (te rahi × 162.0 (176.9 5.9 (matotoru) mm, he maamaa te maimoatanga mata, te taumaha o te kupenga hua ko te 288g (typ.). Ka hoki mai ano tenei hua i te waahanga 6s6p te taha o te taha o te taha 6s6, ko te ora o te puna marama ko te 50k haora, kaore he puku o muri. Ba104S01-100 Whakaputanga LVDS (1 Ch, 6/8-Bit) Atanga tohu, 20 pini, e uru ana ki te urunga urunga, ko te huringa mata te 3.3v. Ko tana reanga whakahekeheketanga noa FV ko te 60Hz. Ka whakahaerehia i te -20 ° C ki te 70 ° C me nga toa i te -30 ° C ki te 80 ° C. E taunaki ana tenei tauira hei whakamahi i nga mahi ahumahi me nga rongoa mo tana rama rama ma, neke atu i te 50,000 haora o te koiora, 6/8 nga waahanga o te tauine hina, me etahi atu waahanga.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Ko enei e whai ake nei ko nga tauira rahi me nga tohu
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Nga Taonga Hot: Boe Ba104s01-100 Te Maama 500nits TFT-LCD Paewhiri, Haina, Tauira, Utu, Maamaa te Matapihi 65. Mata LCD mo te Rōpū o waho , LCD, LCD kōwae, whakaatu kanapa nui.
